36 Cyclone PRO User Manual
CYCLONE PRO
Figure 5-6: RS08 Class Settings
5.1.1.5 HC08
The user may configure the Cyclone PRO to operate on an HC08 target by
selecting HC08 from the Specify Target Architecture drop-down menu.
Alternatively, the user may select the MON08 target through the File menu.
Figure 5.6 shows the HC08 specification configuration.
The target MON08 header connections are shown on the right-hand side for
user reference.
