freightliner cascadia - Engine Fan Switch; Hill Start Aid Override Switch; Automated Transmissions

There is also an engine brake switch located in the
right-hand switch pod on the steering wheel. See
Fig. 5.7. Press the ENG BRK switch once to engage
or disengage the engine brake. Refer to Chapter 13
for instructions on using the engine brake.
Engine Fan Switch
The engine cooling fan can be turned on by the en-
gine fan switch.
To turn the engine fan on, press the upper half of the
switch. The fan will continue to operate for a set
amount of time and then turn off unless the coolant
temperature is high enough to continue fan opera-
tion. To turn the fan off before the set time period
ends, press the lower half of the switch. See
Fig. 5.17.
Hill Start Aid Override Switch
Some vehicles are equipped with a Hill Start Aid
(HSA) feature to prevent the vehicle from rolling
while on steep grades and to allow for a controlled
launch. HSA is "on" by default. It can be turned off
by pressing and releasing the HSA override switch
on the dash (see
Fig. 5.18).
PTO Switch
To activate the PTO function, press the upper half of
the switch. Press the lower half of the switch to de-
activate the PTO function. See
Fig. 5.19.
WARNING
To avoid injury, do not install a PTO that is not
Detroit Diesel approved onto a Detroit
™
Trans-
mission. Use of a non-Detroit Diesel approved
PTO with a Detroit Transmission could result in
unintended operation which could lead to severe
personal injury.
Transmission Controls
Detroit
™
Automated Transmissions
NOTE: See Chapter 15 for complete Detroit
automated transmission operating instructions.
Vehicles with Detroit transmissions use the multifunc-
tion control shown in
Fig. 5.20. This control moves in
two directions and has two switches. It is used to
request manual shifts, change shift mode, set engine
brake levels, and control specialty engine brake func-
tions during cruise control operation.
ENG
BRK
f610905
05/02/2007
HI
LO
Fig. 5.16, Engine Brake Switch
ENG
FAN
f61089902/26/2007
Fig. 5.17, Engine Fan Switch
HSA
OVRD
f61118604/30/2012
Fig. 5.18, Hill Start Aid Override Switch
Driver Controls
5.9
