Frick QUANTUM 4 - Communications Wiring Diagrams

S90-010 M FRICK

QUANTUM™ COMPRESSOR CONTROL PANEL
Page 114 MAINTENANCE
COMMUNICATIONS WIRING DIAGRAMS
TO CUSTOMER REMOTE COMPUTER/DCS
RS-485 COMMUNICATIONS
TO CUSTOMER REMOTE COMPUTER/DCS
RS-422 COMMUNICATIONS
MULTICOMPRESSOR SEQUENCING (LEAD-LAG)
RS-485 COMMUNICATIONS
RWB II / RDB / RXB / RXF MULTICOMPRESSOR SEQUENCING (LEAD-LAG)
RS-422 COMMUNICATIONS
