QUANTUM™ COMPRESSOR CONTROL PANEL S90-010 M
MAINTENANCE Page 55
SLIDE VALVE SETPOINTS
setting default range
Highest Slide Valve Position To Allow
Starting Of The Compressor: ______ 10% 5 - 100%
Starting Period before Slide Valve will load ______ 0 sec. 0 -999
Stopping Period for Slide Valve Unload ______ 60 sec. 0 - 300
Autocycle Minimum Position ______ 10% 0 - 100%
Hot Gas Bypass Or
Slide Valve Setpoint On When Below ______ 0% 0 - 100%
Slide Valve Setpoint 1 On When Below ______ 0% 0 - 100%
Slide Valve Setpoint 2 On When Below ______ 0% 0 - 100%
ECONOMIZER SETPOINTS
On when above Off when below
Slide Valve Position
OPTIONS
SETBACK SCHEDULE
1st Start Time
1st Stop Time
2nd Start Time
2nd Stop Time
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
CONDENSER CONTROL SETPOINTS
Condenser Control Setpoint ______ (range: 0 - 350 psig) (default: 0.0 psig)
Active Not Active
Digital Control
Digital Control Upper Dead Band ______ (range: 0 - 20 psig) (default: 0.0 psig)
Digital Control Upper Dead Band Delay ______ (range: 0 - 60 sec.) (default: 0.0 psig)
Digital Control Lower Dead Band ______ (range: 0 - 20 psig) (default: 0.0 psig)
Digital Control Lower Dead Band Delay ______ (range: 0 - 60 sec.) (default: 0.0 psig)
Condenser Output #1 Sequence Order ______ (range: 0 - 4, 0 = disabled) (default: 0.0 psig)
Condenser Output #2 Sequence Order ______ (range: 0 - 4, 0 = disabled) (default: 0.0 psig)
Condenser Output #3 Sequence Order ______ (range: 0 - 4, 0 = disabled) (default: 0.0 psig)
Condenser Output #4 Sequence Order ** ______ (range: 0 - 4, 0 = disabled) (default: 0.0 psig)
** if only digital was enabled
Analog Control
Analog Control Upper Dead Band ______ (range: 0 - 20 psig) (default: 0.0 psig)
Analog Control Lower Dead Band ______ (range: 0 - 20 psig) (default: 0.0 psig)
Analog Control Response Time ______ (range: 1 - 20 (slow - fast)) (default: 10)
