Frick QUANTUM 4 - PID Setup

S90-010 M FRICK

QUANTUM™ COMPRESSOR CONTROL PANEL
Page 56 MAINTENANCE
PID Setup
Ch. 1 Ch. 2 Ch. 3 Ch. 4 Range Default
Forward
Action
Reverse
Control
______ ______ ______ ______
Setpoint
______ ______ ______ ______
Dependant on Input selected Dependant on Input selected
Deadband
______ ______ ______ ______
Dependant on Input selected Dependant on Input selected
Proportional Gain
______ ______ ______ ______
0.00 - 10000.00 0.00
Integral Gain
______ ______ ______ ______
0.00 - 1000.00 0.00
Derivative Gain
______ ______ ______ ______
0.00 - 10000.00 0.00
High Limit
______ ______ ______ ______
0.0% - 100.0% 100.0%
Low Limit
______ ______ ______ ______
0.0% - 100.0% 0.0%
Off Value
______ ______ ______ ______
0.0% - 100.0% 0.0%
COMPRESSOR SEQUENCE SETPOINTS
Activated De-Activated
Sequence Position A Compressor ID# ______ (range: 0 - 99, 0 = disabled) (default: 0.0 psig)
Sequence Position B Compressor ID# ______ (range: 0 - 99, 0 = disabled) (default: 0.0 psig)
Sequence Position C Compressor ID# ______ (range: 0 - 99, 0 = disabled) (default: 0.0 psig)
Sequence Position D Compressor ID# ______ (range: 0 - 99, 0 = disabled) (default: 0.0 psig)
setting default range
Position A Minimum Slide Valve Position ______ 0% 0 - 100%
Position A Compressor Start Delay ______ 5 min. 0 - 60 min.
Position A Compressor Stop Delay ______ 5 min. 0 - 60 min.
Position A Minimum Compressor Run Time ______ 20 min. 0 - 60 min.
Position B Minimum Slide Valve Position ______ 0% 0 - 100%
Position B Compressor Start Delay ______ 5 min. 0 - 60 min.
Position B Compressor Stop Delay ______ 5 min. 0 - 60 min.
Position B Minimum Compressor Run Time ______ 20 min. 0 - 60 min.
setting default range
Position C Minimum Slide Valve Position ______ 0% 0 - 100%
Position C Compressor Start Delay ______ 5 min. 0 - 60 min.
Position C Compressor Stop Delay ______ 5 min. 0 - 60 min.
Position C Minimum Compressor Run Time ______ 20 min. 0 - 60 min.
Position D Minimum Slide Valve Position ______ 0% 0 - 100%
Position D Compressor Start Delay ______ 5 min. 0 - 60 min.
Position D Compressor Stop Delay ______ 5 min. 0 - 60 min.
Position D Minimum Compressor Run Time ______ 20 min. 0 - 60 min.
Load Limiting Slide Valve Position ______ 0% 0 - 100%
Load Limiting Duration ______ 0 min. 0 - 60 min.
