Frick QUANTUM 4 - Auxiliary Analogs

S90-010 M FRICK

QUANTUM™ COMPRESSOR CONTROL PANEL
Page 58 MAINTENANCE
AUXILIARY ANALOGS
Auxiliary Disabled Text Check Always Check Running
Auxiliary 1
Auxiliary 2
Auxiliary 3
Auxiliary 4
Auxiliary 5
Auxiliary 6
Auxiliary 7
Auxiliary 8
Auxiliary 9
Auxiliary 10 *
Auxiliary
High
Shutdown
**
High
Shutdown
delay***
High
Alarm
**
High
Alarm
delay***
Low
Alarm
**
Low
Alarm
delay**
Low
Shutdown
**
Low
Shutdown
delay***
Auxiliary 1
Auxiliary 2
Auxiliary 3
Auxiliary 4
Auxiliary 5
Auxiliary 6
Auxiliary 7
Auxiliary 8
Auxiliary 9
Auxiliary 10 *
* = Default text is Economizer
** = Pressure range is 30” - 985.3 psig.; Temperature range is -459.4 - 500.0 °F.
*** = 0 - 99 seconds
PUMPDOWN/DX CIRCUITS
Pumpdown on when above
(30.0 Hg - 85.3 psig)
default 20.0 psig
Delay (0 - 60 min.)
default 0 min.
DX Circuit
On when running
Always
On when running
And
at slide valve %
Off when below
(0 - 100) %
Default (85%)
On when above
(0 - 100) %
Default (90%)
1
2
