Frick QUANTUM 4 - Compressor Safeties; Discharge Safeties; Suction Safeties; Entering Process Temperature Safeties

S90-010 M FRICK

QUANTUM™ COMPRESSOR CONTROL PANEL
Page 52 MAINTENANCE
COMPRESSOR SAFETIES
DISCHARGE SAFETIES
setting default range
High Discharge Temp Stop Load ______ 180°F 0 - 249.8°F
High Discharge Temp Force Unload ______ 190°F 0 - 249.8°F
High Discharge Temp Alarm ______ 200°F 0 - 249.8°F
High Discharge Temp Alarm Delay ______ 5 sec. 0 - 60 sec.
High Discharge Temp Shutdown ______ 212°F 0 - 249.8°F
High Discharge Temp Shutdown Delay ______ 5 sec. 0 - 60 sec.
Starting Differential Pressure Below ______ 50 psig 0-380**psig
High Disch Press Mode #1 Stop Load ______ 190 psig 0-380**psig
High Disch Press Mode #1 Force Unload ______ 200 psig 0-380**psig
High Disch Press Mode #1 Alarm ______ 220 psig 0-380**psig
High Disch Press Mode #1 Alarm Delay ______ 2 sec. 0 - 5 sec.
High Disch Press Mode #1 Shutdown ______ 225 psig 0-380**psig
High Disch Press Mode #1 Shutdown
Delay
______ 2 sec. 0 - 5 sec.
High Disch Press Mode #2 Stop Load ______ 190 psig 0-380**psig
High Disch Press Mode #2 Force Unload ______ 200 psig 0-380**psig
High Disch Press Mode #2 Alarm ______ 220 psig 0-380**psig
High Disch Press Mode #2 Alarm Delay ______ 2 sec. 0 - 5 sec.
High Disch Press Mode #2 Shutdown ______ 225 psig 0-380**psig
High Disch Press Mode #2 Shutdown
Delay
______ 2 sec. 0 - 5 sec.
** based on maximum discharge pressure setting in factory setup.
SUCTION SAFETIES
setting default range
High Suction Pressure Stop Load ______ 120 psig 0 - 200 psig
High Suction Pressure Force Unload ______ 130 psig 0 - 200 psig
High Suction Pressure Alarm ______ 140 psig 0 - 200 psig
High Suction Pressure Alarm Delay ______ 2 sec. 0 - 60 sec.
High Suction Pressure Shutdown ______ 150 psig 0 - 200 psig
High Suction Pressure Shutdown Delay ______ 2 sec. 0 - 60 sec.
ENTERING PROCESS TEMPERATURE
setting default range
Low Entering Process Shutdown ______ -463°F -463 - 482°F
Low Entering Process Shutdown Delay ______ 0 sec. 0 - 99 sec.
Low Entering Process Alarm ______ -463°F -463 - 482°F
Low Entering Process Alarm Delay ______ 0 sec. 0 - 99 sec.
High Entering Process Alarm ______ 482°F -463 - 482°F
High Entering Process Alarm Delay ______ 0 sec. 0 - 99 sec.
High Entering Process Shutdown ______ 482°F -463 - 482°F
High Entering Process Shutdown Delay ______ 0 sec. 0 - 99 sec.
HIGH LEVEL SHUTDOWN DELAY
setting default range
High Level Shutdown Delay ______ 5 sec. 0 - 60 sec.
