Froling Lambdatronic H 3200 Service Handbook

Parameters overview | 4
B1820023_en | Service handbook Lambdatronic H 3200 - T4e 53
Pump output of buffer tank – heat exchanger pump
Prerequisite: Hydraulic system 12 or 13
Pump outlet to which the pump between the solar heat
exchanger and buffer tank is connected.
Control of buffer tank – heat exchanger pump
Prerequisite: Hydraulic system 12 or 13
Definition of control signal for pump type used.
Ü "Activation options of pump outlets" [}96]
Pump outlet of DHW tank – heat exchanger pump
Prerequisite: Hydraulic system 12
Pump outlet to which the pump between the solar heat
exchanger and DHW tank is connected.
Control of DHW tank – heat exchanger pump
Prerequisite: Hydraulic system 12
Definition of control signal for pump type used.
Ü "Activation options of pump outlets" [}96]
Invert switch valve output
Prerequisite: Solar system 3, hydraulic system 12 or 13
▪ NO: The pump outlet to which the solar switch valve is
connected is supplied with 230V if the solar panel
system is supplying energy to the DHW tank solar
element or the top part of the buffer tank. If there is not
230V at this output, the valve clears the way to the
buffer tank solar element or the lower area of the buffer
tank.
▪ YES: If the solar switch valve switches incorrectly, the
way it is controlled can be adjusted using this
parameter.
Is a PT1000 sensor used as a solar sensor?
▪ NO: A KTY81 sensor is used as a collector sensor
▪ YES: A PT1000 sensor is used as a collector sensor
Collector pump control Kp value
Control parameter for the speed control of the collector
pump.
Collector pump control Tn value
Control parameter for the speed control of the collector
pump.
Secondary HE pumps control Kp value
Prerequisite: Hydraulic system 12 or 13
Control parameter for the speed control of the pump
between the solar heat exchanger and buffer tank, as well
as for the pump between the solar heat exchanger and
DHW tank (if installed).
Secondary HE pumps control Tn value
Prerequisite: Hydraulic system 12 or 13
Control parameter for the speed control of the pump
between the solar heat exchanger and buffer tank, as well
as for the pump between the solar heat exchanger and
DHW tank (if installed).
Minimum pump speed secondary HE
Prerequisite: Hydraulic system 12 or 13
Adjustment of the minimum speed to the pump type (set
mode of pump in accordance with pump manufacturer).
This parameter applies to the pump between the solar
heat exchanger and the buffer tank, as well as to the
pump between the solar heat exchanger and DHW tank (if
installed).
Control of collector - DHW tank pump
Adjustable parameters for the control type of the pump
between the collector and DHW tank.
Control of the collector - buffer tank pump
Adjustable parameters for the control type of the pump
between the collector and buffer tank.
Pump output of the collector - DHW tank pump
Adjustable parameters for the initial configuration of the
pump between the collector and DHW tank.
Pump output of the collector - buffer tank pump
Adjustable parameters for the initial configuration of the
pump between the collector and buffer tank.
4.3.5 Solar - Heat meter
System menu Solar
Collector temperature
Display of the current temperature at the solar collector.
Collector return temperature
Prerequisite: Hydraulic system 12 or 13
Display of the current temperature at the collector return.
