Parameters overview | 4
B1820023_en | Service handbook Lambdatronic H 3200 - T4e 85
The minimum feed time of the feed screw is
Minimum time that the feed screw is on.
Delivery time feed screw
Time for calculation of feed.
Time feed screw is on until stoker screw
Runtime ratio between feed screw and stoker screw.
The time until the stoker is full is
Total time that the feed screw is on, until the fuel falls onto
the grate (= stoker is full).
The time until the stoker is empty is
Theoretical runtime of the feed screw until there is no
more fuel in the stoker.
Error of light barrier(s) is delayed for
Prerequisite: Overfilling safety device installed for rotary
valve or level sensor installed between feed and stoker
augers
Time delay until an error in the material recognition is
tripped.
During troubleshooting of stoker, it turns forwards
for
Duration, how long should the stoker turn forwards during
troubleshooting of stoker.
During troubleshooting of stoker, it turns
backwards for
Duration, how long should the stoker turn backwards
during troubleshooting of stoker.
During troubleshooting of feed screw, it turns
forwards for
Duration, how long should the feed screw turn forwards
during troubleshooting.
During troubleshooting of feed screw, it turns
backwards for
Duration, how long should the feed screw turn backwards
during troubleshooting.
Motor pause before reversal of the direction of
rotation of the feed screw
At a change of direction, the screw is paused for the set
time.
Set - Cleaning
System menu System Setting
Cleaning
Number of hours heating after which cleaning is
performed
If the boiler has passed the set time in “Heating” status,
the boiler shuts down for a cleaning cycle.
How often is the grate 1 ... 2 rocked during
cleaning?
Defines the number of times the first combustion grate is
rocked during “Rock grate” status.
Permitted start processes with blocked ash screw
Defines the number of boiler start processes that can be
carried while the ash screw is blocked. Once the specified
number has been reached, no further start process is
permitted.
The cleaning may start from
Time from which cleaning is enabled. A time limit for the
heat exchanger function is not recommended.
The cleaning may run until
Time from which cleaning is blocked. A time limit for the
heat exchanger function is not recommended.
Runtime of the cleaning per heating hour
Specifies how long the cleaning per operating hour of the
boiler should be in the heating status. If the boiler is
switched off after 5 hours of heating operation, cleaning
takes five times as long as the time set here.
Minimum duration shutdown
Minimum duration of “Awaiting shutdown” status, in which
the remaining fuel is burned on the combustion grate.
Cleaning after standby
▪ YES: When the boiler switches off, the combustion
chamber grate is only tipped and cleaned after the next
start command. The remaining bed of embers cools
down and when fully cooled falls into the ash screw.
▪ NO: In “Cleaning” operating status, the combustion
grate is rocked and thereby cleaned.
During troubleshooting of ash screw, it reverses
direction for
Specifies how long the ash screw should turn in the
opposite direction in the event of a fault.
