4 | Parameters overview
94 B1820023_en | Service handbook Lambdatronic H 3200 - T4e
4.16.2 Touchscreen - Display operating rights
System menu Touchscreen Display
operating rights
In this menu the operating rights for the individual room consoles are allocated. If access from a room console
to a heating system component is permitted, the corresponding parameter must be set to “YES”. The number of
menus as well as the parameter entries depend on the system configuration!
NOTICE!The operating rights of the room consoles should be allocated from the boiler console, as
unrestricted access is only possible here!
“Touch display with address 1 – 7” and “Button display with address 1 – 7”
Heating circuit system:
Allow access to heating circuit 01 ... 18?
Specifies whether heating circuit 01 … 18 can be
accessed from touchscreen 1 … 7.
DHW tank system:
Allow access to DHW tank 01 ... 08?
Specifies whether DHW tank 01 … 08 can be accessed
from touchscreen 1 … 7.
Buffer tank system:
Allow access to buffer tank 01 ... 04?
Specifies whether the buffer tanks 01 … 04 can be
accessed from the touch screen displays 1 … 7.
Solar panel system:
Allow access to solar system 01?
Specifies whether solar system 01 can be accessed from
touchscreen 1 … 7.
Heating system:
The parameters displayed depend on the configuration.
Boiler:
Switch boiler on/off via room console
If this function is activated, the respective room console is
enabled for switching the boiler on and off. In order to be
able to operate the boiler, remote switching on the boiler
display must also be activated.
