78 B1820023_en | Service handbook Lambdatronic H 3200 - T4e
Release FGR combustion chamber temperature
Specifies the value in percent of the combustion chamber
signal at or above which the flue gas recirculation is
activated. If the combustion chamber temperature falls so
low that the CCT signal falls below this value again, the
flue gas recirculation will be deactivated again.
Start of FGR fan at flue gas temperature
Specifies the minimum activation from which the FGR fan
will be activated.
External elec. sep.
Setting
Flue gas External elec. sep.
State
Electrostatic separator status
Displays the current operating status of the electrostatic
separator as a numeric code. The following statuses are
possible:
▪ Status “0”: Separator deactivated
▪ Status “1”: Separator OFF
▪ Status “2”: Separator ON
▪ Status “3”: Measuring mode
▪ Status “4”: RFI
▪ Status “5”: Wait for bypass flap
▪ Status “6”: Cleaning - Pause
▪ Status “7”: Cleaning - Rinse
▪ Status “8”: Wait for water sensor
▪ Status “9”: Waiting for drying time
▪ Status “10”: Separator error
▪ Status “11”: Quick cleaning
▪ Status “12”: Waiting for drying time
▪ Status “13”: Cleaning – Waiting
▪ Status “14”: Cleaning – Shaking
▪ Status “15”: Cleaning – Waiting
Electrostatic separator return signal
Shows the status of the electrostatic separator as a
numeric code. Following status values are possible:
▪ Status "0": No error
▪ Status "1": Power supply fault
▪ Status "2": RS485 error
▪ Status "3": Temperature box error
▪ Status "4": High voltage error
▪ Status "5": Wait for ready-to-measure state
▪ Status "6": Values critical
▪ Status "7": Measure
▪ Status "8": Measuring mode error
Water detected
Shows the status of the water sensor in the ash drawer. If
the water sensor detects a water level that is too high, the
electrostatic separator is deactivated.
Time until next cleaning
Shows the remaining time (in minutes) until the next
cleaning process.
Electrostatic separator operating hours
Shows the operation hours since the electrostatic
separator was first activated.
Number of cleaning processes
Shows the total number of cleaning processes since the
electrostatic separator was first activated.
