Froling Lambdatronic H 3200 Service Handbook

Parameters overview | 4
B1820023_en | Service handbook Lambdatronic H 3200 - T4e 79
Output level HV module 1 … 4
Displays the current output of the respective HV module
as a numeric code. The following displays are possible:
▪ Output “0”: The current output of the HV module is
between 0 - 25%
▪ Output “1”: The current output of the HV module is
between 25 - 50%
▪ Output “2”: The current output of the HV module is
between 50 - 75%
▪ Output “3”: The current output of the HV module is
above 75%
Service
Enable electrostatic separation function
Used to activate/deactivate the electrostatic separator’s
function. When the electrostatic separator is deactivated,
the bypass flap is open and the flue gas is fed directly into
the chimney.
Time until bypass flap is open
Specifies the time for opening the bypass flap in seconds.
The specified time must correspond at least to the
actuating time of the flap drive.
Close the bypass flap if the electrostatic separator
is inactive
This parameter is set to “NO” by default and should only
be changed after consultation with the manufacturer.
Cleaning interval
Specifies after how many operation hours of the
electrostatic separator a cleaning cycle must be started.
Depending on the raw dust content, this value is set
between 4 and 8 hours.
Duration of cleaning cycle
Defines the total time for a cleaning process. Via this
duration, the spray valve is periodically switched on and
off.
Switch-on duration of spray nozzle. Overall cycle
10 sec
Defines the cycle of the spray valve, which is repeated
until the total time (parameter “Duration of cleaning cycle”)
has elapsed. The cycle of the spray valve is set in
percentages of 10 seconds.
Example: On-time of spray valve: 60%, duration of
cleaning cycle: 23s;
Spray value is switched on for 6 seconds, waits for 4
seconds. This cycle is repeated until the total time is
reached. (6s ON - 4s OFF - 6s ON - 4s OFF - 3s ON)
Drying time
Defines the waiting time after a cleaning cycle before the
HV electrodes are activated again.
Is there a siphon fitted?
By default this parameter is set to “YES” and cleaning of
the filter is performed according to the specified interval.
In case of problems with the drain system (e.g. blocked
duct) this parameter can be set to “NO” in the interim. The
cleaning times are then adjusted so that the collection
tank is not overfilled.
Quick/enforced cleaning active?
Specifies whether the function of the quick/compulsory
cleaning should be active.
Quick/compulsory cleaning: If the output of the HV module
is below 25% for a defined period, a quick cleaning is
carried out during operation. If the output of the HV
module remains below 25%, then a set waiting time is
observed until the next quick cleaning.
Duration of quick cleaning
Defines the on-time of the spray valve during a quick
cleaning.
Minimum time between quick/compulsory cleaning
Specifies the waiting time between two quick cleanings in
minutes.
Cleaning can be performed from
In conjunction with the “Cleaning can be performed until”
parameter, this defines a time window in which the
automatic cleaning of the separator may be activated.
Cleaning can be performed until
In conjunction with the “Cleaning can be performed from”
parameter, this defines a time window within which the
automatic cleaning of the separator may be activated.
