Froling Lambdatronic H 3200 Service Handbook

Parameters overview | 4
B1820023_en | Service handbook Lambdatronic H 3200 - T4e 83
Service
Setpoint under-pressure at cyclone infeed
The cyclone ID fan regulates to this underpressure during
operation.
Minimum ID fan activation at the cyclone separator
Minimum value at which the cyclone separator can be
activated.
Runtime of the ash screw per heating hour
Indicates the length of time during which the ash can be
discharged to the ash container. The duration is
calculated on the basis of the heating hours of the boiler
since the ash screw was last operational.
Cyclone separator Kp under-pressure monitor
Proportional value of the PI controller of the cyclone ID fan
controller.
Tn cyclone separator under-pressure monitor
Reset time of PI controller of cyclone ID fan controller.
Ratio of boiler induced draught fan to cyclone
separator
Determines the ratio to the boiler’s induced draught speed
in which the induced draught of the cyclone separator is
controlled.
Maximum ID fan activation at the cyclone
separator
Maximum ID fan control in the cyclone separator.
Speed monitoring of the cyclone separator ash
screw active
If the speed monitoring function is active, an error
message is output if no feedback is detected at the speed
sensor despite activation of the cyclone separator’s ash
screw.
Target underpressure upstream of the cyclone is
in preparation
During the PREPARATION mode, the negative pressure
in the cyclone is controlled to this setpoint.
IO allocation
AO ID fan cyclone separator
Indicates the analogue module output at which the ID fan
of the cyclone separator is connected.
AI underpressure transmitter
Indicates the analogue module input at which the
underpressure transmitter of the cyclone separator is
connected.
Setting - Ignition
System menu System Setting
Ignition
Feed time until there is a fuel quantity sufficient for
ignition
Feed time until a sufficient quantity of fuel is present on
the combustion grate to carry out the ignition process.
Duration of pre-heating
Time during which only the ignition is activated. The fuel
slide-in is not active for this duration.
Maximum ignition duration
Specifies how long the ignition procedure should last. The
“Heating” status must be reached within this time.
Securely switch off the ignition when above
Flue gas temperature at which the ignition is deactivated
at the latest.
Switch off ignition if the oxygen is reduced by
If an oxygen reduction of 50% of the set value is detected
in the “Pre-heating” operating status, the system
prematurely switches to the “Ignition” operating status.
Infeed during ignition
Defined fuel feed-in for the “Ignition” status duration.
