Froling Turbomatic TMC 70 - Fitting the Noise Protection Hood and Ashcans

Installation
Assembly work
Page 32
M1020008_en s
3
3.3.14 Fitting the noise protection hood and ashcans
U Put the noise protection hood over the cable duct and fix with a
self-tapping screw
 Ensure that the fitted screws engage correctly in the spring
shackles.
 Use a self-tapping screw with a broad head!
U Put the ashcans on the flange of both
ash removal units
