Inverter interior
(13) Door handle (lockable)
(14) Right side panel (opposite: left side panel)
(15)
(16)
Mounting lug (front and rear)
Item Description
Item Designation
(1) Fan
(behind the air inlet grille)
(2) Data communication area
(3) Fuse holder for operation with solar modules grounded to the negative pole:
DC- to PE
(4) 2-pin automatic circuit breaker
to protect the AC power supply
(5) 4-pin automatic circuit breaker
to protect the measuring lines on the grid side
(6) DC main switch
The DC main switch shaft is not fitted when the inverter is delivered.
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
