Fronius Agilo 75.0-3 - Data Communication Area

22
Data communica-
tion area
Item Description
(1)
(2)
for future use
(3) Solar Net IN connection socket
'Fronius Solar Net' input, for connecting to other DATCOM components (e.g. in-
verter, sensor box, etc.)
(4) Solar Net OUT connection socket
'Fronius Solar Net' output, for connecting to other DATCOM components (e.g. in-
verter, sensor box, etc.)
(5) VSR connection socket
for connecting an external measuring and monitoring relay
The contact must be potential-free.
Contact rating 24 V / 10 mA
(1) (2) (3) (4) (5) (6) (7) (10)(8) (9)
