Operating elements and connections
Connections
1
5
2
3
4
(1) Control box mains cable
(2) Control line between welding carriage and control box
(3) Control line between welding carriage and remote control
(4) Connecting lead between control box and power source
(5) Connecting lead for oscillation unit
