Fronius FlexTrack 45 - Weights of Rails and Bridges

71
Weights of rails
and bridges
Magnetic bridge 2.5 kg
Vacuum bridge (on request) 1.6 kg
Magnetic bridge with distance block 2.7 kg
Vacuum bridge with distance block (on request) 1.8 kg
Magnetic bridge with distance block and metric adjustment unit 3.4 kg
Magnetic bridge with metric adjustment unit 3.2 kg
Bridge with adjustable foot, distance block and metric adjustment unit 1.5 kg
Bridge with adjustable foot and metric adjustment unit 1.3 kg
Vacuum bridge with distance block and metric adjustment unit (on request) 2.6 kg
Vacuum bridge with metric adjustment unit (on request) 2.4 kg
Rigid rail 1884 mm 11 kg
Flexible rail 1884 mm 5.5 kg
Flexible rail 1695 mm 4.8 kg
Flexible rail 1130 mm 3.3 kg
Rigid ring Ø200-300 mm 8.8 kg
Rigid ring Ø300-480 mm 11 kg
Rigid ring Ø480-660 mm 14 kg
Rigid ring Ø660-840 mm 16 kg
Rail segment Ø840-1020 mm 19 kg
Rail segment Ø1020-1200 mm 22 kg
Rail segment Ø1200-1380 mm 24 kg
Rail segment Ø1380-1560 mm 27 kg
