Fronius FlexTrack 45 - Configuration: Rail and Guide Rings

32
Structure of a
bridge
(continued)
Bridge with adjustable foot and
metric adjustment unit
Bridge with adjustable foot, metric adjust-
ment unit and distance block
Bridge with adjustable feet
M6x14 screws M6x14 screws
M6x14 screws
Conguration:
rail and guide
rings
l=1130 mm
l=1695 mm
l=1884 mm
Ø200-840mm
Ø 840 - 1380mm Ø 1380 - 1560 mm
Ø 1560 - 6060 mm
l=1130 mm
l=1695 mm
l=1884 mm
Ø200-840mm
Ø 840 - 1380mm Ø 1380 - 1560 mm
Ø 1560 - 6060 mm
l=1130 mm
l=1695 mm
l=1884 mm
Ø200-840mm
Ø 840 - 1380mm Ø 1380 - 1560 mm
Ø 1560 - 6060 mm
on request
on request
