Fronius FlexTrack 45 - Flexible Ring Segments

47
Flexible ring
segments
Flexible ring segments can be joined to create guide rings with a diameter of 1560 mm
to 6060 mm (up to 11 segments). The individual segments are joined to form a guide ring
using M6x20 socket screws.
Flexible segments are available in the following lengths:
SEGMENT
TYPE
LENGTH
Type I 1130 mm
Type II 1695 mm
Type III 1884 mm
The number of segments depends on the pipe diameter and can be selected using the
table below:
Diameter Segments Bridges
1560 - 1740 mm
3x type I
1x type II
18
1740 - 1920 mm
3x type III
1x type I
18
1920 - 2100 mm
3x type III
1x type II
20
2100 - 2280 mm
3x type III
2x type I
21
2280 - 2460 mm 5x type II 25
2460 - 2640 mm
3x type III
2x type II
25
2640 - 2820 mm
5x type II
1x type I
25
2820 - 3000 mm 6x type II 28
3000 - 3180 mm
3x type III
3x type II
30
3180 - 3360 mm 6x type III 30
3360 - 3540 mm 7x type II 33
3540 - 3720 mm
6x type III
1x type I
33
3720 - 3900 mm
6x type III
1x type II
35
Diameter Segments Bridges
3900 - 4080 mm
6x type III
2x type I
36
4080 - 4260 mm
6x type III
1x type II
1x type I
38
4260 - 4440 mm
6x type III
2x type II
40
4440 - 4620 mm
6x type III
1x type II
2x type I
41
4620 - 4800 mm
6x type III
2x type II
1x type I
43
4800 - 4980 mm
6x type III
3x type II
45
4980 - 5160 mm 9x type III 45
5160 - 5340 mm
6x type III
3x type II
1x type I
48
5340 - 5520 mm
9x type III
1x type I
48
5520 - 5700 mm
9x type III
1x type II
50
5700 - 5880 mm
9x type III
2x type I
51
5880 - 6060 mm
9x type III
1x type II
1x type I
53
