Stapler Faults
505
Problem Solving
15
Staple Jams in Staple Cartridge (For Finisher-A1)
This section describes how to clear staple jam occurred in the staple cartridge of the
Finisher-A1 (optional).
1 Make sure that the machine is not operating,
and open the finisher front cover.
2 Take the staple cartridge out of the machine.
Note • The staple cartridge is firmly inserted. A
slight force is required to pull the cartridge
out of the finisher.
3 After you take out the staple cartridge, check
inside of the finisher for any remaining
staples.
4 Pull up the metal part of the staple cartridge
as shown in the illustration.
Be careful in removing jammed staples.
Be careful not to get injured by waste staples when detaching a staple dust box.
Waste staples may come out with output paper. Be careful not to get injured by the
staples.
