Installing the HDD Extension Kit (Optional)
607
Appendix
16
Installing the HDD Extension Kit (Optional)
This section describes how to install the HDD Extension Kit (optional) to the machine.
1 Switch off the power, and then switch off the main power.
For information on how to switch off the power and the main power, refer to "2 Product Overview" >
"Power Source" in the User Guide.
2 Unplug the power cord from the power
outlet.
3 Pull the knob to remove the cover attached
to the rear-left corner of the machine.
4 Loosen the two screws on the cover
attached to the rear-left side of the machine,
by turning them counter-clockwise.
Important • Do not remove the screws, just loosen
them.
