Replacing Consumables
63
Maintenance
3
5 Insert the front side of the new staple case
into the staple cartridge (
c), and then push
the rear side into the cartridge (
d).
6 Push the staple cartridge into the finisher
until it clicks into place.
7 Close the finisher front cover.
Note • If the front cover is not completely closed,
a message will appear and the machine will remain paused.
Replacing Staple Cartridge (for Booklet Maker Unit for Finisher-B1)
When the optional Booklet Maker Unit for Finisher-B1 is installed and the staple
cartridge needs to be replaced, a message appears on the touch screen. When this
message appears, load a new staple case into the staple cartridge.
Important • The use of staple cartridges not recommended by Fuji Xerox may degrade quality and
performance. Use only staple cartridges recommended by Fuji Xerox.
Note • To order a staple cartridge, contact our Customer Support Center.
1 Make sure that the machine is not operating,
and open the side cover of the booklet
maker unit for Finisher-B1.
2 Hold the tabs on both sides of the staple
cartridge and pull the cartridge out of the
finisher.
