16 Appendix
512
Appendix
16
Paper Tray Capacity Standard:
500 sheets × 2trays + 50 sheets (bypass tray)
Optional:
Two Tray Module: 500 sheets × 2
Tandem Tray Module:2000 sheets (900 sheets / 1100 sheets)*
1
2000 sheets (870 sheets / 1130 sheets)
*2
HCF A4 1: 2000 sheets
*1
Measured using fresh P-paper (plain paper) under Temperature
22°C and Humidity 55% environment.
*2
Measured using 4024DP/20lb or 4200/20lb (bond paper) under
Temperature 22°C and Humidity 55% environment, assuming that
the paper thickness is 0.103 mm.
Maximum paper capacity:
5,050 sheets (Standard + Tandem Tray Module + HCF A4 1)
Important • When using 80 gsm paper
Continuous Copy 999 images
Note • The machine may pause temporarily to perform image
stabilization.
Output Tray Capacity Exit 2 Tray: approximately 250 sheets (A4 )
Center tray: approximately 500 sheets (A4 )
Center tray: approximately 250 sheets (A3)
Important • When using 80 gsm paper
Power Supply AC 220-240 V±10%, 8A for both 50/60 Hz ± 3%
Power Consumption Maximum power consumption:
220V: 1.76 kW or less
240V: 1.92 kW or less
Sleep mode:
2W or less
Dimensions DocuCentre-IV 3065/3060/2060:
Width 596 × Depth 640 × Height 1,029 mm
DocuCentre-IV 3065/3060/2060
(with Duplex Automatic Document Feeder):
Width 596 × Depth 640 × Height 1,115 mm
Machine Weight DocuCentre-IV 3065/3060/2060
(with Two Tray Module and Duplex Automatic Document Feeder):
90 kg
DocuCentre-IV 3065/3060/2060
(with Two Tray Module, Duplex Automatic Document Feeder, and
HCF):
121 kg
Important • The weight of paper and the toner cartridges is not included.
Space Requirement Width 1100 × Depth 1548 mm
DocuCentre-IV 3065 DocuCentre-IV 3060 DocuCentre-IV 2060
