Safety Notes
23
Before Using the Machine
1
20
323
80
1783
3006
20
396
With HCF B1-S (Optional) and C3 Finisher with Booklet Maker (Optional)
(Unit: mm)
20
80
1783
3241
20
396
323
With HCF B1-S (Optional), C3 Finisher with Booklet Maker (Optional), and Folder Unit CD1 (Optional)
(Unit: mm)
Do not incline the product at more than 10 degree angle. Otherwise, it may fall
over and cause injuries.
10°10° 10°10°
Front
Front
Left
Left
Back
Back
Right
Right
