Using the Operator Panel Menus 155
NOTE:
• This item is displayed when the Ethernet cable is disconnected and Wireless LAN is set to Enable.
Manual
Setup
Enter (SSID) Specify a name to identify the wireless network. Up to 32
alphanumeric characters can be entered.
Infrastructure Select to configure the wireless settings through the access point
such as a wireless router.
No Security Select to configure the wireless settings with no
encryption settings.
Mixed Mode
PSK
Select to configure the wireless settings with the
Mixed Mode PSK encryption. Mixed Mode PSK
automatically selects the encryption type from
either WPA-PSK-TKIP, WPA-PSK-AES, or WPA2-
PSK-AES.
PassPhrase
Entry
Specify the pass phrase of
alphanumeric characters from 8 to
63.
WEP Select to configure the wireless settings with the
WEP encryption.
WEP Key
Specify the WEP key to use through
the wireless network. For 64bit keys,
enter 10 hexadecimal characters. For
128bit keys, enter 26 hexadecimal
characters.
Transmit
Key
Select a transmit key from Auto,
WEP Key 1, WEP Key 2, WEP Key
3, and WEP Key 4.
WPA-PSK-
TKIP
Select to configure the wireless settings with the
WPA-PSK-TKIP encryption.
PassPhrase
Entry
Specify the pass phrase of
alphanumeric characters from 8 to
63.
WPA2-PSK-
AES
Select to configure the wireless settings with the
WPA2-PSK-AES encryption.
PassPhrase
Entry
Specify the pass phrase of
alphanumeric characters from 8 to
63.
Ad-hoc Select to configure the wireless settings without the access point such
as a wireless router.
No Security Select to configure the wireless settings with no
encryption settings.
WEP Select to configure the wireless settings with the
WEP encryption.
WEP Key
Specify the WEP key to use through
the wireless network. For 64bit keys,
enter 10 hexadecimal characters. For
128bit keys, enter 26 hexadecimal
characters.
Transmit
Key
Select a transmit key from WEP
Key 1, WEP Key 2, WEP Key 3,
and WEP Key 4.
To Next Page
