System expansions
► Press the EasyChange rails into the provided holes.
► Slide the floppy disk slide-in module into the casing (1) until it engages noticeably.
► Fit the data and power supply connectors to the floppy disk drive.
► If it is present, pull the cable of the front USB or USB-audio interface from the mainboard (see
also the manual for the mainboard).
► Attach the front panel (see "Attaching the front panel").
► Close the casing (see "Closing the casing").
i
It may be necessary to modify the entry for the drive in the
BIOS Setup.
52 A26361-K665-Z126-1-19, edition 1
