Insulating Bushing
FNC001629_Rev_01
Figure 18
Aach Insulating Bushings
Step 7
Mount the RU to the pole by aligning the hooks on the plate adapter with the two holes at the top of the wall
mounting plate.
Installation
RU Installation
102
