Insulating Bushing

FNC001626_Rev_01

Figure 24

Adhesive Insulating Bushing

Step 4

Align the holes on the Wall Mount Plate Adapter with the holes on the top of the Wall Mount Plate and hook it in

place.

Installation

RU Installation

108

Release 1.0 · Issue 1.1, May 2021
