Removing and installing com ponents
during servicing
Attaching the cover
2
2
1
► Place th e cover in the correct mounting position (1).
If you remove more tha n one component at the same time, keep the screws for the
individual components separately fro m each other and make sure that you use the
correct screws. If you install the w rong screws, componen ts may be damaged.
► Tighten the screws (2).
► In ser t the battery (se e Chapter "
Install ing the b attery", Page 31).
Finishing component removal
After you have removed or changed the system components a s you required, please
prepare your device for operation again as follows:
► In stall the battery again (see "
Installing the battery", Page 31).
► Turn the notebook the right way up again and place it on a flat surface.
► R eco nnect the cables th at you disconnecte d before.
66 Fujitsu
