FUJITSU DL3100
User’s Manual 5-7
(Auto Paper
Width detection)
Yes: Measures the width of the paper
automatically after loading the
paper.
No: Disables page width
measurement.
NOTE:
The printer is equipped with a page
width sensor called “APW”.
If the sensor is defective, the “APW”
setting will not appear in the menu;
The [Power] LED blinks, [ Font 1]
and [Font 2] have no change,
No: Disables paper width sensor.
Yes: Enables paper width sensor.
When “Yes” and online, pressing the
[Tear Off] key advances the paper to
the tear-off position.
BlackMark commands: (also see
section 5.7)
• 1D 0C:
Feeds paper to the print position
designated by the black mark.
Advance the paper to the tear-off
position after printing.
• 1C 28 4C 03 00 42 m:
m = 0: feeds paper to the print
position designated by the black
mark.
m = 1: feeds paper to the black
8.0inch: The maximum print width
is 80 columns of 10cpi PICA
characters.
Paper Width: Sets the detected page
width as print width. Enabling APW
MicroAdj
-20 -19 -18 -17 -16 -15 -14
-13 -12 -11 -10 -9 -8 -7 -6 -5
-4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18
Fine tunes the form-length by n/360"
(0.07mm) based on the default
value. (Valid for single papers and
fanfolds.)
