Removing and installing components
during servicing
Removing and installing the har
ddisk
Removing a cover
► Remove the battery (see Chapter "Removing the battery", Page 33).
1
2
► Remove the screw (1).
Keep the screws in a safe place. If you are removing m ore than one component at
the same time, store the screws for the individual components separately from each
other. If you install the wrong screws, components may be damaged.
► Lift the cover
off the notebook (2).
Fujitsu Technology Solutions 69
