Removing and installing components
during servicing
Attaching the cover
2
1
► Place the cover in
the correct mounting position (1).
Ifyouremovemore
than one component at the same time, keep the screws for the
individual comp
onents sepa rately from each other and make sure that you use the
correct screws.
If you install the wrong screws, c omponen ts may be dama ged.
► Tighten the screw (2).
► Insert the battery (see Chapter "
Installing battery", Page 33).
Finishing component removal
After you have removed or changed the system components as you required, please
prepare your device for operation again as follows:
► Install the battery again (see "
Installing battery", Page 33).
► Turn the notebook the right way up again and place it on a flat surface.
► R eco nnect the cables that you disconn ecte d before.
72 Fujitsu Technology Solutions
