Removing and installing components
during servicing
Removing a hard disk
1
1
3
2
► Remove the screws (1).
Keep the screws in a safe place. If you are removing more than one component at
the same time, store the screws for the individual compone nts separately from each
other. If you install the w rong screws, components may be damaged.
► Push the hard disk in the direction of the arrow (2) until the contacts disengage.
► Remove the har
d disk from the hard d isk compartment (3).
70 Fujitsu Technology Solutions
