Chapter 1 Preparations
IP-9500e
3
1.1 Main Features
IP-9500e is the video transmission unit with the H.264 encoding technology which performs the high
compression ratio, and transmits the HD (High Definition) video signal in real time through even the
optical IP network like FTTH.
IP-9500e has an encoding function that encodes HD video signals from a HD camera or similar device
and distributes it across the network in real-time. Its decoding function decodes the encoded HD video
signal data received via the network and displays it on a monitor or other device.
Main Features
Item Specifications
HD-SDI 1ch [BNC]
Video input
HDMI 1ch [HDMI]
HD-SDI 1ch [BNC]
HDMI 1ch [HDMI]
Video output
Analog Composite 1ch [BNC] NTSC/PAL
HD-SDI embedded 4ch [BNC], 2 stereo pairs
HDMI 2ch [HDMI]
Audio input
Analog balanced 600Ω 2ch [XLR 3pin], 1 stereo pair
HD-SDI embedded 4ch [BNC], 2 stereo pairs
HDMI 2ch [HDMI]
Audio output
Analog balanced 600Ω 2ch [XLR 3pin], 1 stereo pair
Reference clock input
Analog Composite 75Ω or
Component 75Ω
1ch [BNC]
Voice input/output Analog balanced 600Ω 1ch [RJ25]
Network LAN 2ch
[RJ45],
10BASE-T / 100BASE-TX / 1000BASE-T
Data input/output RS-232C 1ch [D-sub9-pin], male connector
CF CARD slot CF CARD 1 Data storage application
Installation conditions Indoor: On a desk, mounted in a rack
Dimensions
W: 425 H: 42 D: 350 (mm) Note: Excluding protrusions (i.e., not including feet)
W: 430 H: 45 D: 393 (mm) Note: Including FAN, etc
Cooling system Forced air cooling
Power supply 100-240VAC
Weight Maximum 6kg
Power consumption 90W (93VA) or less @ 100VAC
Temperature
Humidity
-10 to 55°C (No low temperature startup: -10 to -1°C)
20 to 90%RH (No condensing)
1.1
