Chapter 2 Installation and Connection
IP-9500e
14
3) The installation of IP-9500e in a rack should be such that the amount of
airflow required for safe operation of IP-9500e is not compromised.
- IP-9500e has ventilation opening at the left and rear side.
- Do not cover or close these ventilation openings to prevent
overheating.
4) The mounting of IP-9500e in a rack should be such that a hazardous
condition in not archived due to uneven mechanical loading. To keep
stability of the entire rack, please fix the rack to wall or floor by
suitable means.
- Be careful about injury during installation of IP-9500e into rack.
- Do not install IP-9500e into your rack where IP-9500e mau make
the entire rack unstable.
- The weight of IP-9500e with the maximum configuration: 6 kg
5) If IP-9500e is supplied from the power strip or the service outlet of
other units, it may overload the power supply cord of the power strip or
other units.
- Confirm that the current rating of the power strip or the service
outlet exceeds the combined ratings of all equipment is supplying.
- The electrical rating of IP-9500e: Rated 100-240 VAC, 0.93-0.44 A,
50/60 Hz, 1 phase.
6) The reliable earthing of the rack-mounted equipment must be
maintained. The particular attention should be given to supply
connections other than direct connections to the branch circuit (e.g., use
of the power strips or the power distribution unit).
Note: The high leakage current may flow through the power strip
earthing conductor if all power supply cords of IP-9500e are connected
to one power strip. The earth connection is essential before connecting
supply. If the power strip is not directly connected to the branch circuit,
the power strip which has the industrial type attachment plug should be
used.
7) For installing, IP-9500e shall be installed near the wall-outlet and the
wall-outlet shall be easily accessible.
2.1.3 Air flow into and out from the device
IP-9500e is forced air cooled. Be sure not to block the air intake/exhaust vents. Provide an
adequate amount of space around the vents.
