Chapter 1 Preparations
IP-9500e
8
No. Names Description
(30)
SDI video input
(SDI IN)
Digital HD-SDI video input terminal. 75Ω unbalanced.
See Section 2.3, “Audio and Video Device Connections,” for an explanation on
using this terminal. See Section 4.2, “Cable and Connector Details,” for cable
connection information.
(31)
SDI video output
(SDI OUT)
Digital HD-SDI video output terminal. 75Ω unbalanced.
See Section 2.3, “Audio and Video Device Connections,” for an explanation on
using this terminal. See Section 4.2, “Cable and Connector Details,” for cable
connection information.
(32)
Video output
(ANALOG VIDEO OUT)
Analog video output terminal. 75Ω unbalanced.
See section 2.3, “Audio and Video Device Connections,” for an explanation on
using this terminal. See Section 4.2, “Cable and Connector Details,” for cable
connection information.
(33)
Reference clock signal
input
(GENLOCK IN)
External clock signal input terminal. 75Ω unbalanced.
See Section 2.3, “Audio and Video Device Connections,” for an explanation on
using this terminal. See Section 4.2, “Cable and Connector Details,” for cable
connection information.
(34)
Optional card slot
Optional card slot.
(35)
Blank panel
Remove when the optional card is equipped. See Section 2.7, “Optional card
insertion” for removing or insertion of the optional card.
(36)
Screws
Screws to fix the optional card. See Section 2.8, “Optional card insertion” for
removing or insertion of the optional card.
