Chapter 3 Operation instructions
IP-9500e
36
The items in the Settings window are listed in the table below:
Item Explanation
LAN IP address Displays the IP address on LAN.
Default: 10.0.0.1
LAN Subnet mask Displays the subnet mask on LAN.
Default: 255.0.0.0
Gateway Displays the gateway address.
Default: 0.0.0.0
CONSOLE IP address Displays the IP address on CONSOLE.
Default: 192.168.255.253
CONSOLE Subnet mask Displays the subnet mask on CONSOLE.
Default: 255.255.255.252
When you operate the IP-9500e with the default settings after shipment from the
factory, disconnect the IP-9500e from your network. Connect it to the setting
terminal via a Hub or directly. Install the software in the setting terminal, and
then set up the IP-9500e to meet the requirements for your network and then
connect the IP-9500e to the network. If you connect the IP-9500e to your
network with the default settings, an unexpected problem may be caused with
your network.
