Chapter 4 Cable specifications
IP-9500e
54
(5) HDMI cable
<IP-9500e>
①
Front view
ＨＤＭＩ
<External device side>
ＨＤＭＩ
TMDS DATA2 +
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
⑪
⑫
⑬
⑭
⑮
⑯
⑰
⑱
⑲
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
⑪
⑫
⑬
⑭
⑮
⑯
⑰
⑱
⑲
TMDS DATA2
SHIELD
TMDS DATA2 -
TMDS DATA1 +
TMDS DATA1
SHIELD
TMDS DATA1 -
TMDS DATA0 +
TMDS DATA0
SHIELD
TMDS DATA0 -
TMDS CLOCK +
TMDS CLOCK
SHIELD
TMDS CLOCK -
CEC
RESERVE(N.C.)
SCL
SDA
DDC/CEC GROUND
+5V POWER
HOT PLUG
DETECT
TMDS DATA2 +
TMDS DATA2
SHIELD
TMDS DATA2 -
TMDS DATA1 +
TMDS DATA1
SHIELD
TMDS DATA1 -
TMDS DATA0 +
TMDS DATA0
SHIELD
TMDS DATA0 -
TMDS CLOCK +
TMDS CLOCK
SHIELD
TMDS CLOCK -
CEC
RESERVE(N.C.)
SCL
SDA
DDC/CEC GROUND
+5V POWER
HOT PLUG
DETECT
Length of the attested HDMI cable is pretermission.
The unattested cable can't be used.
HDMI cable with HDMI connector
