Chapter 4 Cable specifications
IP-9500e
58
(9) 100 - 240 VAC power cord
The power supply cable is not contained in this device. Please prepare the cable which suits the
country which uses it.
Other
Connector specifications
Connector pin assignment
L1 L2
FG
<Device side>
Front view of cable connector
{
If a power cord with a ground wire cannot be used, connect the FG terminal to
an external ground . (See Section 2.2.1, "Connection to ground.")
The form of an outlet changes
with countries which use it.
To standard two - prong power receptacle with ground
(x: length specification)
c
c
c
c
c
c
L1
L2
FG
L1
L2
FG
USABLE DETACHABLE POWER SUPPLY CORD SET
MODEL Input Connector Cord Attachment Plug cap
North
America
<*1>
<*2>
100-
120V
IEC C-13
Rated 13A, 125V
UL, CSA Approved
Type SJT, No.16 AWG Min.
3-Conductors
(Single phase;2-current carrying
conductors & ground)
UL, CSA Approved
NEMA (5-15P)
parallel blade
Rated 13A, 125V
UL, CSA Approved
200-
240V
IEC C-13
Rated 15A, 250V
UL, CSA Approved
Type SJT, No.14 AWG Min.
3-Conductors
(Single phase; 2-current carrying
conductors & ground)
UL, CSA Approved
NEMA (6-15P)
tandem blade
Rated 15 A, 250 V
UL, CSA Approved
Europe
<*2>
100-
240V
IEC C-13
Rated 10A, 250V
<*1>
CENELEC OC
3X1.0 square mm<*1>
<HAR>
Rated 10 A, 250 V
<*1>
Aus-
tralia
100-
240V
IEC C-13
Rated 10A,
250V
Cable: AS OD 3 X1.0 square mm
e.g.
Rated 10 A, 250 V
U.K
<*2>
100-
240V
IEC C-13
Rated 10A,
250V
BS OC 3 X1.00 square mm Rated 10 A. 250 V
IEC C-13
Rated 13A,
125V
Type HVCTF cross section area
1.25 square mm
3-Conductors
(Single phase;2-current
carrying conductors & ground)
NEMA (5-15P)
parallel blade
Rated 13 A, 125 V
Japan
100V
METI Approved
or <PSE>
METI Approved
or <PSE>
METI Approved
or <PSE>
or
ASA
PS
E
PS
E
PS
E
To Next Page
