Fujitsu ScanSnap S1300 User Manual

Replacing the Pick Roller
294
5. Rotate the bushing (left).
6. Remove the pick roller shaft.
Slightly pull up the left part of the pick roller shaft (about 5 mm), move it towards the left
side, and then pull it up to remove it from the ScanSnap.
The area around the pick roller may get dirty due to paper dust, and cause scan errors.
Remove the dirt using a dry cloth moistened with Cleaner F1 in order to prevent such
errors.
Do not use any water, mild detergent or air spray.
Pick roller shaft
Bushing
Pick roller
Pick roller
Pick roller shaft

Fujitsu ScanSnap S1300 Specifications

General

Film scanning	No
Color scanning	Yes
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	10 sheets
USB version	2.0
Standard interfaces	USB 2.0
Scan media weight	64 - 104.7 g/m²
Dimensions (WxDxH)	284 x 99 x 77 mm
Power requirements	AC 100 - 240V, 50/ 60 Hz
Non-operating relative humidity (non-condensing)	20 - 80 %
Minimum RAM	512 MB
Minimum storage drive space	2197 MB
Sustainability certificates	ENERGY STAR
Power consumption (standby)	5 W
Power consumption (typical)	9 W
Operating temperature (T-T)	5 - 35 °C
Certification	RoHS

Weight and Dimensions

Depth	99 mm
Width	284 mm
Height	77 mm
Weight	1400 g
