Ports and co nt rols
Left-hand side
2 3 4 5 6 71
1 = Tether eyelet
2 = Combined headphones and microphone
port (audio combo jack)
3 = USB 3.0 port (protected by cover)
4 = microHDMI port (protected by cover)
5 = microSD card slot ( prote cted by cover)
6 = Battery charging indicator ( ora nge)
7 = DC input connector (DC IN)
(protected by cover)
Right side
2 3 4 5 6 71
1 = USB 2.0 port (protected by cover)
2 = Shortcut button
3 = Volume down button
4 = Volume u p button
5 = ON/O FF button
6 = Stylus garage
7 = Tether eyelet
Fujitsu 11
