Fujitsu STYLISTIC V535 User Manual

Contents
ConfiguringWLANaccess ........................................................... 42
FurtherinformationonWLANandBluetooth ........................................... 42
NFC(NearFieldCommunication) ..................................................... 42
GPS ................................................................................... 42
Accessories fo r your Tablet PC (optional) . ............................................. 43
Your Universal Docking Cradle / your Universal Charging Cradle with AC adapter (optional) .... 43
Cradle components . . ................................................................ 44
EthernetandLAN(onlywithUniversalDockingCradle) ................................ 45
Settingupthecradle ................................................................ 46
Removingtheattachmentfromthecradle ............................................. 46
Connecting the Tablet PC to the cradle . . ............................................. 47
Disconnecting the Tablet PC from the cradle . ......................................... 48
Chip and Pin shell (Ingenico iCMP co mpatible), (optional) .................................. 49
Magnetic Stripe Reader shell (optional) . . ................................................. 51
SmartCardshell(optional) .............................................................. 53
Rugged Case (optional) . ................................................................ 55
Full USB to LAN Conversion Adapter . . . . ................................................. 57
Securityfunctions ..................................................................... 58
Using the security lock (optional) . ........................................................ 58
ConfiguringpasswordprotectioninBIOSSetupUtility ...................................... 59
Protecting BIOS Setup Utility (supervisor password a nd user password) . . ............... 59
Password protection for booting the operating system .................................. 60
Smart Card reader (optional) . ............................................................ 61
Mounting the Smart Card reader . . . . . ................................................. 61
InsertingtheSmartCard ............................................................. 62
Connectingexternaldevices ........................................................... 63
Connecting an external monitor . . ........................................................ 63
HDMIport(UniversalDockingCradleonly) ............................................ 63
Connecting USB devices (Tablet PC or Universal Docking Cradle) .......................... 64
HowtoremoveUSBdevicescorrectly ................................................ 64
Audiocombojack ....................................................................... 65
Settings in BIOS Setup Utility . . ........................................................ 66
StartingtheBIOSSetupUtility ........................................................... 66
ExitingBIOSSetupUtility ................................................................ 67
Exit Saving Changes - save changes and exit BIOS Setup Utility . . . . ................... 67
Exit Discarding C hanges - R eject changes and exit BIOS Setup Utility ................... 67
LoadSetupDefaults–loaddefaultvalues ............................................. 67
Discard Changes - Discard Changes without exiting BIOS Setup Utility . . . ............... 67
Save Changes - save changes without exiting the BIOS Setup Utility . ................... 67
Save changes and power off ........................................................ 67
Troubleshootingand tips .............................................................. 68
Executingareset ....................................................................... 69
Forcedshutdown .................................................................... 69
Executeacompletereset:ResetBIOSSetuptothestandardvalues .................... 69
Helpifproblemsoccur ................................................................... 69
RecoveringyourFactoryImage .......................................................... 69
TheTabletPC’sdateortimeisincorrect .................................................. 69
Batteryindicatordoesnotilluminate ...................................................... 70
TheTabletPC’stouchscreenremainsdark ................................................ 70
4 Fujitsu

Fujitsu STYLISTIC V535 Specifications

General

Stepping	C0
Processor code	SR1SK
Processor cache	2 MB
Processor cores	4
System bus rate	- GT/s
Processor family	Intel Atom®
Processor series	Intel Atom Z3700 Series
Processor codename	Bay Trail
Motherboard chipset	Intel BayTrail-T SoC
Processor frequency	1.59 GHz
Processor cache type	L2
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	17 x 17 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor boost frequency	2.39 GHz
Processor operating modes	32-bit, 64-bit
Scenario Design Power (SDP)	2 W
Internal memory	4 GB
Memory clock speed	1066 MHz
Internal memory type	LPDDR3-SDRAM
Storage media	-
Compatible memory cards	MicroSD (TransFlash)
Internal storage capacity	64 GB
Display diagonal	8.3 \
Touch technology	Multi-touch
Display brightness	400 cd/m²
Display resolution	1920 x 1200 pixels
Native aspect ratio	16:10
Graphics card	HD Graphics
Rear camera type	Single camera
Rear camera resolution (numeric)	8 MP
Front camera resolution (numeric)	2 MP
Number of built-in speakers	2
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Microphone in	No
USB 2.0 ports quantity	1
Device type	Mobile tablet
Form factor	Slate
Product color	Black
Cable lock slot type	Kensington
Sustainability certificates	RoHS
Certification	CE, EN 60950, IT-Eco-Declaration, RoHS, WEEE, GOST
Battery capacity	4425 mAh
Battery life (max)	6.5 h
Battery recharge time	5 h
AC adapter power	36 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3 A
AC adapter output voltage	12 V
Platform	Windows
Operating system version	64
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Processor ARK ID	80267
Processor socket	BGA 1380

Weight and Dimensions

Depth	12.5 mm
Width	227.8 mm
Height	150.1 mm
Weight	540 g
