Appendix A.3 Checking Wiring and Settings

• No COMS on Modbus RTU side. If the Tx/Rx LEDs are not flashing rapidly then there is a COM

issue. To fix this, check the following:

o Visual observations of LEDs on ProtoNode (Appendix A.4)

o Check baud rate, parity, data bits, stop bits

o Check Detector ID matches the correct device

o Verify wiring

o Verify the device was listed under the Web Configurator Active Profiles (Section 6.3)

• Field COM problems:

o Visual observations of LEDs on the ProtoNode (Appendix A.4)

o Verify IP Address setting

o Verify wiring

NOTE: If the problem still exists, a Diagnostic Capture needs to be taken and sent to technical

support. (Appendix A.5)
