Fulton ProtoNode Start-up Guide
Page 46 of 47
Appendix D Reference
Appendix D.1 Specifications
One 3-pin Phoenix connector with: RS-485/RS-232 (Tx+ / Rx- / gnd)
One 3-pin Phoenix connector with: RS-485 (Tx+ / Rx- / gnd)
One 3-pin Phoenix connector with: Power port (+ / - / Frame-gnd)
One Ethernet 10/100 BaseT port
Input Voltage: 9-30VDC or 24VAC Current draw: 24VAC 0.125A
Max Power: 3 Watts 9-30VDC 0.25A @12VDC
CE and FCC class B & C part 15, UL 60950, WEEE compliant, IC
Canada, RoHS compliant, DNP 3.0 conformance tested
4 x 1.1 x 2.7 in (10.16 x 2.8 x 6.8 cm)
-20°C to 70°C (-4°F to158°F)
Figure 34: Specifications
Appendix D.1.1 Compliance with UL Regulations
For UL compliance, the following instructions must be met when operating ProtoNode.
• The units shall be powered by listed LPS or Class 2 power supply suited to the expected operating
temperature range.
• The interconnecting power connector and power cable shall:
o Comply with local electrical code
o Be suited to the expected operating temperature range
o Meet the current and voltage rating for ProtoNode
• Furthermore, the interconnecting power cable shall:
o Be of length not exceeding 3.05m (118.3”)
o Be constructed of materials rated VW-1, FT-1 or better
• If the unit is to be installed in an operating environment with a temperature above 65 °C, it should
be installed in a Restricted Access Area requiring a key or a special tool to gain access.
• This device must not be connected to a LAN segment with outdoor wiring.
Specifications subject to change without notice.
