5.3 BURNER FLAME SENSOR TEST
Figure. 23 - Flame Sensor
Thistestcheckstheoperationoftheamesafeguardsensor.
1. Ensurethattheburnerisring.
2. Removetheamesensorfromitsplug-inconnectiononthetopoftheburner.
3. Cover the sensor glass to exclude all light.
4. Theburnercontrolshouldgotoalockout/amefailurecondition(2-3secgas,34secoil)and
will require manual resetting.
Note: The fan will run on for a short time but the ame should go out.

used.
5. Clean the UV photocell before replacing it.
6. Press the Common Alarm Reset button.
7. Checktheburnerautomaticallystartsupandres.
Flame sensor
Mains gas
supply
Observation glass
