Page 71
TROUBLESHOOTING - 6
238/254 Building Technologies Division Basic documentation LMV26... CC1P7547en 30 Error code list 20.04.2016 Error code Diagnostic code Meaning for the LMV26... system Remedy
present - Check wiring to see if there is a short-circuit
1
Fuel valve 2 (V2) leaking (fuel valve 1 with valve proving via X5-01)
For valve proving via X5-01 (gas pressure switch-min) - Check to see if the valve on the gas side is leaking - Check wiring to see if there is a short-circuit
2 Valve proving not possible
Valve proving activated, but pressure switch-min selected as input function for X9-04 (check parameters 238 and 241)
3 Valve proving not possible
Valve proving activated, but no input assigned (check parameters 236 and 237)
4 Valve proving not possible
Valve proving activated, but 2 inputs assigned (set parameter 237 to pressure switch-max or POC)
5 Valve proving not possible
Valve proving activated, but 2 inputs assigned (check parameters 236 and 237)
81 V1 leaking
Check to see if the valve on the gas side is leaking Check wiring to see if there is an open-circuit
83 V2 leaking
Check to see if the valve on the burner side is leaking Check to see if the pressure switch for the leakage test is closed when gas pressure is present Check wiring for short-circuit
14 # POC 0 POC open
Check to see if the valve’s closing contact is closed
1 POC close
Check wiring Check to see if the valve’s closing contact opens when valve is controlled
64 POC open – prevention of startup
Check wiring to see if there is a line interruption. Check to see if the valve’s closing contact is closed
19
80 Combustion pressure, POC – start prevention
Check to see if pressure switch has closed with no combustion pressure present Check wiring for short-circuit
20 # Pressure switch-min (Pmin)
0 No minimum gas / oil pressure
Check wiring for line interruption
1 Gas shortage / prevention of startup
Check wiring for line interruption
21
0 Pressure switch-max (Pmax): Max. gas / oil pressure exceeded
Check wiring to see if there is a line interruption.
22 OFF S
# Safety loop / burner flange
0 Safety loop / burner flange open 1 Safety loop / burner flange open - prevention of startup 3 Safety loop/burner flange, extraneous light – start prevention 5 Safety loop/burner flange, air pressure – start prevention 17 Safety loop/burner flange, combustion pressure – start prevention 19
Safety loop/burner flange, extraneous light, combustion pressure – start prevention
21 Safety loop/burner flange, air pressure, combustion pressure – start
