FULTON VMP Series - Page 93

VMP-IOMM-2018-2
Fulton Ltd
Page 85
APPENDIX - A
Specication
TI-128-VMP-DS-2017-3
Page 2 of 2
Every effort is made to ensure accuracy at time of going to press. However as part of our policy of continual product improvement, we reserve the right to alter specications without prior notice.
Telephone: +44 (0) 117 972 3322
Fax: +44 (0) 117 972 3358
E-mail: sales@fulton.co.uk
Website: www.fulton.co.uk
Fulton Ltd
5 Fernhurst Road, Fishponds, Bristol.
BS5 7FG. England.
MODEL: VMP UNIT 60 80 100
CE marked to PED, EMC, LVD & Machinery Directive, constructed to BS2790 as standard (other code specications
available).
General
Steam Output F & A 100°C * kg/h 939 1252 1565
kW Rating kW 600 800 1000
Operating Pressure barg 10.34 10.34 10.34
Weight
Shipping Weight kg 3340 3630 4310
Operational Weight kg 4190 5330 6590
Water Content L 1022 1450 1960
Efciencies
Gross % 83 83 83
Net % 92 92 92
Gas Pressures
Min. Natural Gas Modulating mbar 50 50 50
Min. Natural Gas Hi/Low mbar 18 23 23
Max. Natural Gas mbar 150 150 150
Min. LPG mbar 50 50 50
Max. LPG mbar 80 80 80
Firing Rate **
Gas m
3
/h 68 90 113
Oil L/h 64.3 87 106
LPG/Propane m
3
/h 27 36 45
Ventilation Requirements for Consumption Purposes (Free Area)
Low Level inlet cm
2
4030 5250 6520
High Level Outlet cm
2
2015 2625 3260
Electrical Requirements ***
FLC 400 V 3 ph 50 Hz A/ph 3.8 5.5 5.5
FLC 230 V 1 ph 50 Hz A 11.8 17.3 17.3
Connection Sizes All threads BSP F= Female, M=Male
Steam Outlet DN 80 F 80 F 80 F
Safety Valve Discharge (x2) DN 25 F 32 F 32 F
Feedwater Inlet DN 25 M 25 M 25 M
Feedwater Pump Inlet DN 25 F 25 F 25 F
Blowdown, Boiler DN 40 M 40 M 50 M
Blowdown, Water Column DN 20 F 20 F 20 F
Blowdown, Water Level Gauge
(Sight Glass)
DN 8 F 8 F 8 F
Blowdown, TDS DN 20 M 20 M 20 M
Flue Outlet in. 12 14 14
Water Sample Outlet DN 15 M 15 M 15 M
Gas Inlet DN 40 F 50 F 50 F
Oil Connection Flexible hoses provided 1/2 in. BSP all models.
* Steam Output - at 100 °C feedwater temperature, 0 psig.
** Consumption based on Natural Gas 10.35 kW/m
3
; Propane 25 kW/m
3
, and Light Oil 11 kW/L.
*** Electrical requirements may vary if additional controls are added.
Note: 18 mbar - 28 mbar gas pressure is required during run for 40-60 HP boilers with standard burners. 23 mbar - 28 mbar gas pressure is
required during run for 80-100 HP boilers with standard CSD-1 burners, 100 mbar is required for 130 -150 HP.
Note: Electrical enclosures are rated IP20
