SYSTEM CONFIGURATION
CATEGORY OF UNITS
Antenna Unit: Exposed to Weather
Communication Unit: Protected from Weather
Other Units: Protected from Weather
PERSONAL
COMPUTER
(PC/AT compatible)
ANTENNA
UNIT
IC-116
COMMUNICATION UNIT IC-216
(with internal GPS receiver)
SHIP'S MAINS
100-115/200-230 VAC
1φ, 50/60 Hz
: Standard
: Option
: Local Supply
SHIP'S MAINS
12-24 VDC
AC-DC
Power Supply
PR-240
POWER
I
O
INMARSAT MINI-C MOBILE EARTH STATION
FURUNO
POWER
LOGIN
TX
ERROR
PRINTER
JUNCTION BOX
IC-315
SSAS ALERT UNIT
IC-307
SSAS ALERT UNIT
IC-307
* : SSAS Specification
*
