6. OTHER FUNCTIONS
6-4
6.4 Choosing NCS Channel
You may select NCS common channel as shown below. Currently, each satellite
transmits one global beam. In the future, the satellites will transmit multiple spot
beams, namely, the NCS will have multiple channels.
The below procedure is provided for reference.
1. Press the [F7] key to display the Options menu.
2. Press the [4] key to display the NCS Channel List.
1. Login
2. Logout
3. Abort
4. Select NCS
5. Ocean Region
6. Test
Options
NCS Channel List
No
AOR (WEST)
FREQ
11080*
ID
044
0
0
0
0
0
0
0
01
02
03
04
05
06
07
08
ENTER: Set ESC: Quit
AOR (EAST)
FREQ
12580*
ID
144
1
1
1
1
1
1
1
POR
FREQ
12580*
ID
244
2
2
2
2
2
2
2
IOR
FREQ
10840*
ID
344
3
3
3
3
3
3
3
NCS channel list
3. Choose desired channel and then press the [Enter] key. Then, the FELCOM
16 starts to synchronize with the NCS channel selected.
4. Press the [Esc] key to return to the standby display.
